Stubby (https://dnsprivacy.org/wiki/display/DP/DNS+Privacy+Daemon+-+Stubby) is a DNS privacy stub resolver. Stubby, among other things, does support DNS-over-TLS (RFC 7858 "Specification for DNS over Transport Layer Security (TLS)" https://tools.ietf.org/html/rfc7858).

• Stubby availability in pre-compiled form (status December 2017)
  • Homebrew (MacOS X)
  • Chocolatey (Windows)
  • Manjaro-Linux
  • Arch-Linux
  • Windows Installer https://dnsprivacy.org/wiki/display/DP/Windows+installer+for+Stubby

This document describes the installation from source on Fedora Linux 27:

This command will start Stubby on the commandline in foreground. This is a test if the configuration is valid. After the test, terminate Stubby with CTRL+C.

sudo /usr/local/bin/stubby -l

register the new unit file in systemd and start Stubby

systemctl daemon-reload
systemctl enable --now stubby
systemctl status stubby

Now the enhanced security of privacy of stubby is available for all applications on the system.

shell> delve dnsworkshop.org
; fully validated
dnsworkshop.org.        3600    IN      A       91.190.147.212
dnsworkshop.org.        3600    IN      RRSIG   A 8 2 3600 20140318181408 20140216173922 63654 dnsworkshop.org. qS9/slk/jvcMc7+HSTMFD1D7GfuW5LIgBj0J1vCCCP5X+g9puhDdRSMM dURzelY6wsPVaUgtx44azEoJYHmNwFJlSsALPnekC6DWjKYMhzYilpUl OKAIZQh5lZxs3oimZHe6GEpEfkZ3ZV0IDTLLe4pIKRXoxDQ2eRJ543GD iTk=

Without extra arguments, delve will query the local DNS server (taken from /etc/resolv.conf) for an IPv4-Address record at the given domain name. It tries to validate the answer received, prints the result of the validation, the requested data and the RRSIG Record (DNSSEC signature) used to verify the data.

As with dig, resource record types and network classes can be given in almost any order on the commandline. The switch +multi (for multiline) enables pretty printing; human readable output that is nearly formatted for a 78 column screen.

shell> delve dnsworkshop.org soa +multi
; fully validated
dnsworkshop.org.        3600 IN SOA ns1.myinfrastructure.org. hostmaster.strotmann.de. (
                                86         ; serial
                                86400      ; refresh (1 day)
                                7200       ; retry (2 hours)
                                3542400    ; expire (5 weeks 6 days)
                                3600       ; minimum (1 hour)
                                )
dnsworkshop.org.        3600 IN RRSIG SOA 8 2 3600 (
                                20140321030247 20140219020247 63654 dnsworkshop.org.
                                O8mmiuNdXIWG6huaLiQrvKabDY3qivQ3R5qRUZ1IG3wp
                                bd0UBnvpazpG01ntk8uZ7wEStScmiY7oYtvRGIHG37mG
                                8GFI60CUx3pdXJIpmodfoUBk8cfGsJXFQODIZCTUQiyk
                                Pv9I6+wjyseDJJTYlrsBCvAEabPExFKZc7v+L+k= )

and IPv6

shell> delve dnsworkshop.org AAAA +multi
; fully validated
dnsworkshop.org.        7200 IN AAAA 2001:470:1f08:f1d::2
dnsworkshop.org.        7200 IN RRSIG AAAA 8 2 7200 (
                                20140321025727 20140219020247 63654 dnsworkshop.org.
                                gqkc1Xq/UveKrhcXpqOwDsN5HFSqMsPkxXOyCqu9bMyx
                                dtnkh0J0Iqukv+uHL/dDQLnPcxjdFqs3N5Jf3BFHdgkG
                                tf0UPhNKsuhlsRdo2H5O+TqmLvA1zCsYhH/72vVvxslR
                                MiiuZ1ILGpLA2EOyiZu70/ZIU3Ypc3nb8+ydgx4= )

delve comes with a set of trace switches that can help troubleshoot DNSSEC validation issues. The first switch, +rtrace, prints the extra DNS lookups delve performs to validate the answer:

delve dnsworkshop.org mx +multi +rtrace
;; fetch: dnsworkshop.org/MX
;; fetch: dnsworkshop.org/DNSKEY
;; fetch: dnsworkshop.org/DS
;; fetch: org/DNSKEY
;; fetch: org/DS
;; fetch: ./DNSKEY
; fully validated
dnsworkshop.org.        3600 IN MX 100 mail.strotmann.de.
dnsworkshop.org.        3600 IN RRSIG MX 8 2 3600 (
                                20140308193355 20140206183355 63654 dnsworkshop.org.
                                hCOcPJrDCXpcVS82FgGEdUhaUmW3XkxXEuEa4AFvzkzi
                                mDcokYNjrW/Hay4NclSWV0jrBwrXABXik5dh7w7KsPkD
                                WKhw/qVvkuiFCm+T5lb9OVkGQAuPhBOplbVgdbZce9L7
                                N2IVTQTLMECKfzCTfKeOtwupJAMPXCt/Xskd5o4= )

In this example, in addition to the MX-Record (Mail-Exchanger) Record, the DNSKEY record (DNSSEC public key) and the DS record (Delegation signer) for dnsworkshop.org, as well as the DNSKEY and DS records for ORG and the DNSKEY for the root-zone "." have been requested. The trust-anchor for the Internet Root-Zone is compiled into delve and acts as the starting trust anchor for the validation.

The switch +mtrace prints the content of any additional DNS records that have been fetched for validation.

+vtrace prints out the DNSSEC chain of validation:

shell> delve _443._tcp.dnsworkshop.org TLSA  +multi +vtrace
;; fetch: _443._tcp.dnsworkshop.org/TLSA
;; validating _443._tcp.dnsworkshop.org/TLSA: starting
;; validating _443._tcp.dnsworkshop.org/TLSA: attempting positive response validation
;; fetch: dnsworkshop.org/DNSKEY
;; validating dnsworkshop.org/DNSKEY: starting
;; validating dnsworkshop.org/DNSKEY: attempting positive response validation
;; fetch: dnsworkshop.org/DS
;; validating dnsworkshop.org/DS: starting
;; validating dnsworkshop.org/DS: attempting positive response validation
;; fetch: org/DNSKEY
;; validating org/DNSKEY: starting
;; validating org/DNSKEY: attempting positive response validation
;; fetch: org/DS
;; validating org/DS: starting
;; validating org/DS: attempting positive response validation
;; fetch: ./DNSKEY
;; validating ./DNSKEY: starting
;; validating ./DNSKEY: attempting positive response validation
;; validating ./DNSKEY: verify rdataset (keyid=19036): success
;; validating ./DNSKEY: signed by trusted key; marking as secure
;; validating org/DS: in fetch_callback_validator
;; validating org/DS: keyset with trust secure
;; validating org/DS: resuming validate
;; validating org/DS: verify rdataset (keyid=33655): success
;; validating org/DS: marking as secure, noqname proof not needed
;; validating org/DNSKEY: in dsfetched
;; validating org/DNSKEY: dsset with trust secure
;; validating org/DNSKEY: verify rdataset (keyid=21366): success
;; validating org/DNSKEY: marking as secure (DS)
;; validating dnsworkshop.org/DS: in fetch_callback_validator
;; validating dnsworkshop.org/DS: keyset with trust secure
;; validating dnsworkshop.org/DS: resuming validate
;; validating dnsworkshop.org/DS: verify rdataset (keyid=24209): success
;; validating dnsworkshop.org/DS: marking as secure, noqname proof not needed
;; validating dnsworkshop.org/DNSKEY: in dsfetched
;; validating dnsworkshop.org/DNSKEY: dsset with trust secure
;; validating dnsworkshop.org/DNSKEY: verify rdataset (keyid=2611): success
;; validating dnsworkshop.org/DNSKEY: marking as secure (DS)
;; validating _443._tcp.dnsworkshop.org/TLSA: in fetch_callback_validator
;; validating _443._tcp.dnsworkshop.org/TLSA: keyset with trust secure
;; validating _443._tcp.dnsworkshop.org/TLSA: resuming validate
;; validating _443._tcp.dnsworkshop.org/TLSA: verify rdataset (keyid=63654): success
;; validating _443._tcp.dnsworkshop.org/TLSA: marking as secure, noqname proof not needed
; fully validated
_443._tcp.dnsworkshop.org. 3544 IN TLSA 3 0 1 (
                                3E5E70BBA957CA0DAFCB799F15F6236133C0F6C73FA7
                                3762BFFBCA4AF92389CA )
_443._tcp.dnsworkshop.org. 3544 IN RRSIG TLSA 8 4 3600 (
                                20140309145739 20140207135739 63654 dnsworkshop.org.
                                JYkLiFqvrjqiIlm/bA4CaffJ3Iikos31bfEVb2njjIR+
                                /7dudq9pAj898OVZrtqIjmfD7knyCT2nt6Gp/yFYif4k
                                Tt7W2XMhnWecwRnFexhVYp1zg2dkZSw4XcBRMz/F2NkM
                                0xziG9dNFg/6AAs/0ehMurLvRj1ula/UIO/wU5w= )

delve is a very useful tool, not only for BIND 9 admins, but for everyone who needs to troubleshoot and fix DNS- and DNSSEC related issues.

Sometimes I get this question in my DNSSEC training classes: "now DNSSEC seems to be a good technology, but the root-zone is controlled by the US government. Because of that, can we trust DNSSEC?".

My answer is not to mix technology (DNSSEC) with implementation (the DNS system of the Internet).

Both are separate. While I can understand that some people do not trust the organisations in control of the Internet DNS root-zone, I see no flaw in DNSSEC (at this moment).

One way to solve the trust issue with the Internet root-zone is to host your own root-zone for the Internet. Then you are in full control of that zone. Have that zone in your own network, or on your Laptop computer und use it for the starting.point of all DNSSEC validation (the trust anchor) for DNS.

Besides the trust question, there might be another reason to operate a local root-zone: some organisations have created an internal, private top-level domain (TLD)¹. A local, dnssec-signed root-zone enables the operator to remove or add any delegations, while still being able to validate all DNSSEC signed data in the Internet, as well as data that is stored in their own private DNS namespace.

The following tutorial explains the steps required to generate a local augmented and DNSSEC signed root-zone. The tutorial requires some understanding of DNS concepts and basic knowledge on DNSSEC. A good starting point to learn about DNSSEC (besides a training) is the book DNSSEC mastery by Michael W. Lucas.

All the tools used are part of the BIND DNS Server for ISC (Internet Systems Consortium). This tutorial has been tested using BIND 9.9.4-P1. Older or newer versions of BIND might require a different setup.

We need one or more authoritative servers to host the augmented root-zone. For production deployments in an internal network, at least two authoritative servers are required. For a local root-zone on a mobile device (Laptop etc.), one single authoritative server might be good enough.

We also need at least one caching DNS server (smart resolver). This cannot be the same DNS server instance as the authoritative server, however it is possible to run both (caching and authoritative server) on the same machine, but have them listen to different IP addresses. In this tutorial, I will use two separate machines:

• authoritative server: a.myroot-server.loc:192.0.2.53
• caching server: cache.loc:192.0.2.153

On both servers, the BIND configuration file will be in /etc/named.conf and the BIND "data" directory will be /var/named.

The operating-system used is Debian 7.x.

We start with a basic BIND named.conf configuration file for a caching, validating DNS Server:

acl myclients { 192.0.2.0/24; localhost; };

options {
        directory "/var/named";
        allow-recursion { myclients; };
        dnssec-enable yes;
        dnssec-validation yes;
        dnssec-lookaside auto;
};

logging {
    channel syslog { syslog daemon; severity info; };
    channel security { file "security.log" versions 10 size 50M; print-time yes; };
    channel query_log {
      file "query.log" versions 10 size 50M; severity debug; print-time yes;
    };
    category general       { syslog; };
    category security      { security; };
    category queries       { query_log; };
    category dnssec        { security; };
    category default       { syslog; };
    category resolver      { syslog; };
    category client        { syslog; };
    category query-errors  { query_log; };
    category edns-disabled { syslog; };
};

managed-keys {
  "." initial-key 257 3 8      "AwEAAcFN/moqnq1SxdGnZW9JigGYgmFx5WN68RKJ90Je
                                61LJVXi8pKFRz+rajcAu7g7hb0o56RGShWkIWJAosOGr
                                O4onzJ5t+h+rwRNe7EX++KI9XJobzHp+LQiOi/eo2cze
                                91oik9+9Tr+NzyJsssOEq9X/mm9hP44a8YgqSzR+rwCb
                                8jeB9WPhQk25Sp7qN3o8WLCfDxFy6ioOFa7MFirUa1dK
                                30B92X10JN0KA3d0UmOJ3GU50T0WSbWq15k28qX0et/M
                                W3Wl3T5CclG0goM19ET0iQPJh4mN3Gdw9bHqDyiPsqeP
                                MRJNzjb+EgK+MOp3eAqbQ1hlnr/ruwOMKz6oEIYviec8
                                QWvJShmeY4+rRCL5lzZuQ7AYOQq8QO4jUnqTe2/t/Oqy
                                o6yqOtiwsLjmgnsK11qZojJ9RSzjb1r5D5Icl5UHGNxG
                                O6/CQYJMHFsyksYzc1Brtg1PdyHc1zy/GFNI6QEQzlhQ
                                H1nTa+F2MnoZp3k1Z6PTh+GU1796jNtUhMgy4pN7dOqC
                                35hP3GzaP3/XkXtzWbpZRgcXNahbiKso8eqt3r45MCsK
                                AsW3r3hg+CzujTOjVBveKhGfb3nQvx702IdW6Jy62HWX
                                TvipTuG1Kqw+zWHofR2P0ugAszYQBL7G3Zo45VtEScwP
                                XaWavSbGNnHJH5OQQT6HnDvF8hZP";
};

zone "." {
        type hint;
        file "root.hint";
};

The managed-key is the DNSKEY record of our private root-zone. We get that record with the query:

shell> dig @192.0.2.53 . DNSKEY | grep 257

This will request the DNSKEY record set from the private root-server, the grep will filter out the key-signing-key (KSK) with the flag field of "257"³.

The file root.hint will contain the root-hints (NS records and A/AAAA records of our authoritative DNS servers for the private root-zone):

shell> dig @192.0.2.53 ns .

; <<>> DiG 9.9.4-P1 <<>> @192.0.2.53 ns .
; (1 server found)
;; global options: +cmd
;; Got answer:
;; ->>HEADER<<- opcode: QUERY, status: NOERROR, id: 3958
;; flags: qr aa rd; QUERY: 1, ANSWER: 1, AUTHORITY: 0, ADDITIONAL: 2
;; WARNING: recursion requested but not available

;; OPT PSEUDOSECTION:
; EDNS: version: 0, flags:; udp: 4096
;; QUESTION SECTION:
;.                              IN      NS

;; ANSWER SECTION:
.                       518400  IN      NS      a.myroot-servers.loc.

;; ADDITIONAL SECTION:
a.myroot-servers.loc.   86400   IN      A       192.0.2.53

;; Query time: 15 msec
;; SERVER: 192.0.2.53#53(192.0.2.53)
;; WHEN: Sun Dec 22 15:06:50 CET 2013
;; MSG SIZE  rcvd: 77

This data can be redirected into the file:

shell> dig @192.0.2.53 ns . > root.hint

Next, we check that the BIND configuration is error free …

shell> named-checkconf -z

and if no error is shown, we start the BIND DNS Server:

shell> named
shell> tail /var/log/syslog
Dec 22 18:19:13 raspidev named[2384]: automatic empty zone: 9.E.F.IP6.ARPA
Dec 22 18:19:13 raspidev named[2384]: automatic empty zone: A.E.F.IP6.ARPA
Dec 22 18:19:13 raspidev named[2384]: automatic empty zone: B.E.F.IP6.ARPA
Dec 22 18:19:13 raspidev named[2384]: automatic empty zone: 8.B.D.0.1.0.0.2.IP6.ARPA
Dec 22 18:19:13 raspidev named[2384]: command channel listening on 127.0.0.1#953
Dec 22 18:19:13 raspidev named[2384]: command channel listening on ::1#953
Dec 22 18:19:13 raspidev named[2384]: managed-keys-zone: loaded serial 9
Dec 22 18:19:13 raspidev named[2384]: all zones loaded
Dec 22 18:19:13 raspidev named[2384]: running

Now, on the caching server, we should be able to validate out own root zone (watch for the AD-Flag):

; <<>> DiG 9.9.4-P1 <<>> @localhost soa . +adflag +m
; (2 servers found)
;; global options: +cmd
;; Got answer:
;; ->>HEADER<<- opcode: QUERY, status: NOERROR, id: 13316
;; flags: qr rd ra ad; QUERY: 1, ANSWER: 1, AUTHORITY: 1, ADDITIONAL: 1

;; OPT PSEUDOSECTION:
; EDNS: version: 0, flags:; udp: 4096
;; QUESTION SECTION:
;.                      IN SOA

;; ANSWER SECTION:
.                       86327 IN SOA a.myroot-servers.loc. nstld.verisign-grs.com. (
                                2013122200 ; serial
                                1800       ; refresh (30 minutes)
                                900        ; retry (15 minutes)
                                604800     ; expire (1 week)
                                86400      ; minimum (1 day)
;; AUTHORITY SECTION:
.                       518274 IN NS a.myroot-servers.loc.

;; Query time: 3 msec
;; SERVER: 127.0.0.1#53(127.0.0.1)
;; WHEN: Sun Dec 22 15:13:02 CET 2013
;; MSG SIZE  rcvd: 118

And we should also be able to validate other data out in the Internet, like the domain name for this blog (dnsworkshop.de or dnsworkshop.org):

; <<>> DiG 9.9.4-P1 <<>> dnsworkshop.de @localhost
;; global options: +cmd
;; Got answer:
;; ->>HEADER<<- opcode: QUERY, status: NOERROR, id: 60851
;; flags: qr rd ra ad; QUERY: 1, ANSWER: 1, AUTHORITY: 2, ADDITIONAL: 1

;; OPT PSEUDOSECTION:
; EDNS: version: 0, flags:; udp: 4096
;; QUESTION SECTION:
;dnsworkshop.de.                        IN      A

;; ANSWER SECTION:
dnsworkshop.de.         7200    IN      A       91.190.147.212

;; AUTHORITY SECTION:
dnsworkshop.de.         7200    IN      NS      ns2.myinfrastructure.org.
dnsworkshop.de.         7200    IN      NS      ns1.myinfrastructure.org.

;; Query time: 1230 msec
;; SERVER: 127.0.0.1#53(127.0.0.1)
;; WHEN: Sun Dec 22 15:14:16 CET 2013
;; MSG SIZE  rcvd: 115

And we can also validate our augmented .loc TLD that does not exist in the public Internet:

; <<>> DiG 9.9.4-P1 <<>> @localhost a.myroot-servers.loc +adflag
; (2 servers found)
;; global options: +cmd
;; Got answer:
;; ->>HEADER<<- opcode: QUERY, status: NOERROR, id: 15859
;; flags: qr rd ra ad; QUERY: 1, ANSWER: 1, AUTHORITY: 1, ADDITIONAL: 1

;; OPT PSEUDOSECTION:
; EDNS: version: 0, flags:; udp: 4096
;; QUESTION SECTION:
;a.myroot-servers.loc.          IN      A

;; ANSWER SECTION:
a.myroot-servers.loc.   86400   IN      A       192.0.2.53

;; AUTHORITY SECTION:
loc.                    86399   IN      NS      a.myroot-servers.loc.

;; Query time: 94 msec
;; SERVER: 127.0.0.1#53(127.0.0.1)
;; WHEN: Sun Dec 22 18:22:33 CET 2013
;; MSG SIZE  rcvd: 79

Voila, a DNSSEC signed local root-zone.

The root-zone is a busy place right now. New TLDs are added all the time. Make sure you follow these changes. A good way to get notice of updates in the root zone is to follow @diffroot on Twitter. Please remember, if you followed this tutorial, you need to add the changes using nsupdate, do not use a text editor on the zone files!

1] I do not recomment hosting a private TLD, it is much easier and less error-prone to run a private DNS delegation on the second or third level of the DNS hierachy, such as private.example.com.

2] Be sure to use the double >> to append to the file, a single > will override the zonefile with the keys. Not what we want.

3] Always double check the key data, there is a slight chance that the sequence "257" will appear in the key material of the ZSK as well!

./static/Mirror-Mirror_files/mirror-mirror.pdf

• BCP 38 - "Network Ingress Filtering: Defeating Denial of Service Attacks which employ IP Source Address Spoofing"
• BCP 140 - "Preventing Use of Recursive Nameservers in Reflector Attacks"

• DSC: A DNS STATISTICS COLLECTOR
• dnstop
• dns wittness
• PacketQ
• Analysing DNS traffic using PacketQ

• John Kristoff - Open Resolvers and the Threat of Reflection Attacks (PDF)
• Joe Abley - DNS Reflection Attacks (PDF)

• OpenDNS Resolver Project
• DNS survey: open resolvers
• The Million Plus Open Resolver Challenge
• Animation showing an amplification attack (Team Cymru; Quicktime)
• CIO Magazine: Open DNS Resolvers Increasingly Abused to Amplify DDoS Attacks, Report Says

• 7 Jan 2013 What switching on "minimal responses" in BIND does to your average response size
• Decreasing your DNS footprint by 102 bytes
• BIND 9 Administration Manual

• Tony Finch - Rate limiting DNS
• BIND 9 patches by Paul Vixie and Vernon Schryver
• BIND 9 binaries for MacOS X, Debian, RedHat, Solaris with RRL patches applied (look for RRL in the filename)
• DNS Dampening by Lutz Donnerhacke
• DNS Response Rate Limit in NSD
• RRL in the Knot DNS Server (CZ.NIC Labs)
• BIND 10 RRL checkin information

• 4 Ways to Prepare for and Fend Off DDoS Attacks
• How to Launch a 65Gbps DDoS, and How to Stop One
